WinTV v6 can be used with any WinTV-PVR TV tuner.

Name Network Format 1: 12: 10 Bold: Ten Network: 576i 2: 21: ABC: ABC: 576i 3: SBS: SBS: 576i 7: 71: Seven: 7 Network: 576i 9: 91: Nine: Nine. VidLink Channel Lineup; VidLink Voice Search; VidLink How-to Guides; OptiLink Channel Lineup; OptiLink TV Listings; Watch TV Everywhere; Watch ESPN; Phone. Packages + Pricing; GA Relay Service; OptiLink Legal; BUSINESS. Business; Internet. Packages + Pricing; TV. VidLink Packages + Pricing; VidLink Channel Lineup; VidLink Voice Search; VidLink. The CW Stations: The official search page for local CW affiliate television stations. Find out where you can watch The CW in your area. Sr.No Channel Name Channel Number; 1: Lok Sabha: 115: 2: DD News: 116: 3: DD India: 117: 4: Rajya Sabha: 118: 5: DD Kisan: 119: 6: ABP News: 120: 7: News 24: 121: 8.

After the installation of the WinTV v6 application, you find see a shortcut 'Hauppauge WinTV' in the Windows Start menu and the WinTV icon on your Windows desktop.

Basic control of WinTV v6:

To remove the TV tools (called 'No Title mode'), click your RIGHT mouse button once in the live TV area. To see the TV tools again, click your RIGHT mouse button once in the live TV area. In each mode, you can set the position and size of the WinTV window.
Watch TV full screen: click the Full screen button. Click your RIGHT mouse button or hit the ESC key to exit full screen mode.
Changing TV channels: Click Channel Up or Channel down. Or RIGHT click in the TV channel window which will display the current TV channel list for fast channel changing. You can also change channels by using the numbers on the keyboard or by pressing the letter on the keyboard for the channel name that you want to view.
Record TV: click the red Record button (which is next to the TV channel window) to start recording. You can set a record timer but clicking the red record button once for each 15 minutes you'd like to record. When you are finished recording, click the TV button. You can automatically schedule a recording by using the Hauppauge WinTV Scheduler.
Audio setting: RIGHT click the mouse button on the 'audio type/language selection' you can change the available audio language settings of the current TV program that you are watching.
Control menu: click the Menu botton, or RIGHT click and hold the mouse button (hold for 2 seconds) in the TV window, the control options are displayed.

In order to re-size the window, move the mouse pointer to the edge of the TV window. This changes the mouse pointer into a double arrow. Press and hold the left hand mouse button and drag the window into the desired size, releasing the left mouse button when finished.

WinTV Scheduler with built-in support for TitanTV

This version of the Hauppauge WinTV v6 Scheduler supports TitanTV, the web based TV electronic program guide.

To use TitanTV, go to www.TitanTV.com, and register, choosing your local TV provider. If you have a Hauppauge WinTV installed. simply click the Record button when viewing the details of any TV program.

Note: You need an internet connection to use titantv.com

Location Manager with QAM channel mapper

Win Channel Number On Dish Tv

The Location Manager allows you to save a channel list, and give it a name. For example, if you are in Chicago and scan for TV channels, you can then save this list and call it 'Chicago'.

If you then visit Milwaukee, you can scan for channels and use WinTV, but when you return to Chicago you can use Location Manager to select the Chicago channel list.

The Location Manager also has a QAM channel mapper, which allows you to map QAM channels to the channel list from TitanTV. For example, let's say you scan for QAM channels and find that channel number 2703 is really CNN. You can use the QAM channel mapper to tell the Scheduler that when you click on CNN in TitanTV, that CNN is found on QAM channel 2703.

Click here for instructions on using the QAM mapper.

Note: You need an internet connection to use the QAM channel mapper.

Name: hcwlocmgr_setup.exe
Version: 2.0.27029

Zap2It EPG plug-in for WinTV Scheduler

This is a third party plug-in for the Zap2It Electronic program guide, and uses the WinTV v6 Scheduler.
This EPG has support for the U.S. and Canada.

To use this guide, go to www.Zap2It.com and register using your Zip or Postal code. Then, click on TV Listings. When you see a program you want to record, click the program listing and then click 'Record to WinTV'.

Note: to uninstall this plug-in, use the Add/Remove programs from Control Panel. Make sure you have Explorer turned off before you try to uninstall this plug in.

Note: you need an internet connection to use Zap2It.

Name: epg_for_haup_1.00.04.exe

Installation instructions for the WinTV v6 CD

Note: WinTV v6 is compatible with all WinTV-PVR products. In 64-bit versions of Windows 7 and Windows Vista, the WinTV-PVR-150, WinTV-PVR-250, WinTV-PVR-350 and WinTV-PVR-500 require the use of less than 4GB of memory.

Installation note:

A valid WinTV application CDROM will be needed to install this WinTV v6 version. Any WinTV-NOVA version 4x, WinTV-PVR, WinTV version 6 or WinTV v7 application CD can be used during the install. If you do not have your original WinTV CD-ROM but would like to update to this WinTV v6 version, you can purchase a new CD on the Hauppauge webstore.

Local Tv Channel Numbers

Supported WinTV products:

This version of WinTV v6 is for the WinTV-PVR and analog WinTV series of products. It can be used with the following WinTV products:

In addition, WinTV v6 can be used with the European equivalents of the above models.

Note: This is a single file which includes the driver, the driver update, middleware, video decoder and WinTV v6 applications and all accessories. This file is larger than the individual pieces, but should be easier to install since it is in one file.
Note: this package is for Windows XP, Windows XP Media Center Edition, Windows Vista and Windows 7.

Installation Procedure

Step 1 - Software download
Please click on the download link from your products support page, you will be given an option to Run or Save the file., Click Run to start the installation procedure:
Once the file has finished downloading, the self extracting wizard will begin:
Click Next then select a path where you wish to extract the files (we recommend leaving this at its default setting), the Hauppauge software and drivers will be extracted automatically to your computer.
Step 2 - Previous software removal
If you have a previous version of the software installed you will be prompted to uninstall it, click OK to automatically do this.
The 'HCWClear.exe' application will start up and begin uninstalling the previous software, any error messages or notes will be shown in the black box.
Once complete you may need to restart your computer, press 'OK' to automatically restart your computer.
Step 3 - Installation of the drivers
After Windows reboots, you will see the Windows Found New Hardware Wizard, please select 'Ask me again later' in Vista or simply cancel this wizard in XP (it may appear several times, repeat this each time the wizard is shown):
Once you are at your desktop, double click on the link to the install application:
This will open up the Hauppauge install application, click 'Step 1: Install Drivers':
This will then open up our driver installation program and automatically start installing the drivers for your product:
Once complete click on the bar to continue.
Step 4 - Installation of the WinTV Software and other applications
In the Hauppauge installer you will now need to click 'Step 2: Install WinTV':
Select the language you wish to install from the list. Note: If you wish to customize the install list click on 'Custom Installation'.
The applications relevant to your product will now be shown and will begin to install: Note: Installing may take some time as it is updating other system components, please be patient. Once complete click 'OK' then click 'EXIT'.

WinTV version 6 users manual

WinTV version 6 users manual
Updated: October 15, 2007

Prodinfo: get information on your Hauppauge TV tuner

Prodinfo.exe is a program you can run which will extract information about the WinTV product you have installed such as model and serial number, MAC address, revision, and features which can be used to identify the exact model of your product. The driver for the device must be installed in order to run Prodinfo.exe

HCWClear: remove the Hauppauge driver and applications from your PC

HCWCLEAR.exe is a program you run to remove all driver and files that were installed with the installation of the WinTV program.

Using the WinTV6 Application

Basic operation

Channel changing

You can change channels by using the Channel Up or Channel Down buttons on the WinTV.
You can also type a channel number (for example:27) and WinTV will tune to that channel.

Volume change

With the slide bar on the top left hand side of the WinTV application window you can change the Volume level. Alternatively you can use the keypad on the keyboard <PgUp> for volume up or <PgDn> for volume down.

Sound on / off

To mute the sound on or off click on the green button below the slider bar. Alternatively you can use the keys on the keyboard <CTRL> + <M>.

Last channel

Clicking the “last channel” button will allow you to quickly change to the last viewed channel.

Surf preview

Clicking on the button 'Surf' will show up to 16 still image preview of TV channels that you have scanned. The screen will gradually fill and double clicking on one of the preview images will show the selected channel in full screen.

Always on top

With Always on Top, WinTV will always be visible on your Windows desktop on top any applications. To turn on, click the Always on top button. It will turn green. To turn off, click this button again. A convenient way to use Always-on-Top is to make the TV window in the no-title mode small, and to make the TV window in the title mode larger. Then you can switch very quickly from a small window to a larger one by clicking the right mouse button.

TV mode

Click on the button 'TV mode', in order to watch television in the full screen TV mode. With one click to the right mouse button or press the <ESC> key to leave TV mode.

To hide the WinTV toolbar (No-title mode)

Click your right mouse button in the WinTV’s video window for the no-title mode. To restore

the toolbars (the title mode), once again click your right mouse button in the video window.

You can set the size of the window differently in each mode.

Freeze picture

Click on the button Freeze, around the picture 'to freeze'. Clicking on Freeze will un Freeze the picture.

Snapshot

Clicking on the “Camera” symbol will take a snapshot still picture of the Video window that you are viewing. A 'Thumbnail' (preview made smaller) of the still image of the video window will appear in the snapshot preview border. Double click on the 'Thumbnail', to see it in full size. Now you can save the picture using option in the menu 'file'/'save under...' on your hard disk. Clicking the Button CFG allows you to configure the snapshot function.

Saving several snapshots at the same time

Highlight the first image and then hold down the <SHIFT> key on the keyboard and then highlight the subsequent images that you want to save. Once you have selected the images that you want to save release the <SHIFT> key and then right click on a image to select the SAVE to file option.

Channel Menu

To display the channel configuration menu <right> click with the mouse button on the TV window:

The channel configuration allows you to configure using the following options:

Position the mouse pointer on the channel that you want to select and click the <Left> hand mouse button to select.
Use the <Up> and <Down> and <Left> and <Right> arrow keys on the keyboard to select the different sub-menu that you want to select and press Enter / Return
To select a channel list of either TV or Radio you can filter for either TV or Radio channels to be show in the channel list. The channel can also be selected by pressing the 1st letter of the channel name on the keyboard.

How to set up TV channels

On the WinTV v6 application, click on the MENU button.
Click on “Suite Manager” to open the WinTV Channel Manager.
The Channel Manager has tabs for 'Scan', 'Sources', 'Devices' and 'Channels'.

NOTE: To save your WinTV channel list, you may save the file HcwChanDB_5.mdb (which is located in the C:/users/public/wintv:for vista/windows 7 or C:Documents and SettingsAll UsersDocumentsWinTV: for XP) into a temporary folder, and copy this file back into the WinTV directory after any re-installation to preserve your channel list.

Scan for Analog channels

This section refers to analog TV from cable TV or a TV antenna.

To scan for analogTV channels, click on the Sources tab.

Under Input Sources, click on Analog Source.

Automatic scanning for channels

Set the Country and Source (i.e. Cable TV, Antenna, HRC), then click Autoscan. WinTV will scan through the possible channels and list those where a video signal is detected.

The channel frequencies will scan from 1 to 69 for antenna, or 1 to 125 for cable. When channels are found they will be listed and the scanning will continue. After the completion of the channel scan a new window of an overview of the scanned frequencies and the number of found programs are will be displayed.
With an analog source, you may uncheck the AFT box to disable 'automatic fine tune', and control fine tuning of the channels frequency by moving the slider (this control has a range of +127 to -128 db). Once you complete your fine tuning settings, you must click the Add button, which will add this frequency as a new channel into the WinTV suite manager. You can then delete the original channel if you are replacing it with the newer fine tuned one.
Tuning Mode provides two settings - one lists channels by country; the other lists all channels. The Broadcast/Cable item selects the appropriate Tuner mode for your input signal. Video Format and Country items select area of operation; WinTV provides all major video formats

Note: WinTV will be unavailable during the scan process.

You can track progress at the Channel Dialog's upper right corner. When the process is finished, all available channels will be displayed in the Channel Dialog.

Unwanted Channels may be deleted from an input source by simply selecting them and pressing the Delete key from the channel list menu.

Manual channel search

You can shorten the channel scan if you know the channel numbers for your local transmitter by entering the numbers into the channel number and click on Tune.

Scan for ATSC or Clear QAM digital TV channels

Note: This section refers to products with an ATSC/Clear QAM tuner (WinTV-HVR series).

Under Input Sources, select the ATSC Source or Clear QAM Source. ATSC is the digital TV format from 'over-the-air' digital TV in North America. Clear QAM is unencrypted digital cable TV.

Automatic channel search

Click the <Autoscan> button to start the search for ATSC channels, ensure that you have selected your country location. The channel search will count from 1 to 125 and when a signal is found the box locked will have a tick.

Manual channel search

You can shorten the channel scan if you know the Multiplex Channel Numbers for your local digital transmitter by entering the numbers into the Channel Number and click on Tune

NOTE: To save your WinTV channel list, you may save the file HcwChanDB_4.mdb (which is located in the C:Program FilesWinTV directory) into a temporary folder, and copy this file back into the WinTV directory after any re-installation to preserve your channel list.

QAM channel mapping

To install:

Download the Location Manager and run it.
Open WinTV v6.
Click on the Menu button. You will see the Location Manager and QAM Mapper which is the QAM channel mapper.

To use the QAM channel mapper

Open WinTV v6 and click on the Menu button.
Click on QAM Mapping
Enter your Zip code (currently the QAM mapper only works in the U.S.) When you click 'OK', the QAM mapper will retrieve the channel listings for your Zip code. This takes about 1 minute.
You then need to select the service type (satellite, digital cable, etc.) and the cable TV provider you are using.
Then click the Mapping button.

You will see two columns. The left column is the channels as they have been scanned by WinTV v6. The right column are the channels which are used in the TitanTV Electronic Program Guide.

Now you can associate the scanned channels to the TitanTV EPG channels so you can use TtitanTV to schedule recordings on QAM channels. For example, let's say that WinTV v6 channel 'qam-605' is really QVC, and you want to schedule QVC recordings from TitanTV.

You would then find QVC in the TtitanTV column, drag and drop it on qam-605. Then, click Save.

Now, when you schedule a recording on QVC using TtitanTV, the Hauppauge WinTV Scheduler will switch to QAM channel 605 for the recording.

Setting up an external audio/video source to the WinTV

Configuration a Video Input

When connecting a external source to the WinTV, please ensure that the cables are connected in the correct order.
Note: This section refers to WinTV products with Video Input.

Connecting WinTV to a VCR, camcorder, or a satellite or cable TV set top box

If your VCR or Set top box, such as a satellite TV set top box such as a DirecTV box or a SkyTV box, has a S-video output and your WinTV product has S-video input ,then you can use a S-video to S-video cable. This connection will give you the best video quality for analog video.
For sound input, you will connect the Red and White RCA jacks on your set top box to the WinTV. Some WinTV's have separate Red/White RCA jacks. Others have a 1/8' stereo jack. If your WinTV uses Red and White RCA jacks, use RCA cables (readable available at most electronic resellers). If your WinTV uses a 1/8' stereo input jack, you will need a 1/8' stereo to Red/White RCA jack adapter. This can also be found at most electronic retailers.

Connecting WinTV to Sony PS2, PS3 or XBox360 (or any other game device)

On WinTV products with built-in hardware MPEG-2 encoders, there is a slight lag between the game input and what you will see on your PC screen. If you are recording the video game, this will not matter. But if you intend to use your PC screen to play the video game, you might find this effect to be problematic.

For the video input to the WinTV product, S-Video will give you the best video quality for analog video. For sound input, you will connect the Red and White RCA jacks on your game to the WinTV. Some WinTV's have separate Red/White RCA jacks. Others have a 1/8' stereo jack. If your WinTV uses Red and White RCA jacks, use RCA cables (available at most electronic resellers). If your WinTV uses a 1/8' stereo input jack, you will need a 1/8' stereo to Red/White RCA jack adapter. This can also be found at most electronic retailers.

Configuring WinTV to use the external S-Video or Composite audio/video source

On WinTV v6, click on the MENU button and then click Suite-Manager to open the WinTV Channel Manager
Select the Sources tab and highlight the video source you are using to connect to your external source, either Composite or S-video source
Set the Video Format. In Europe, the video format is Pal-BGHIDK. The video format used in North America is NTSC
Type a Name for the channel in the field 'Name' and a description
Click on <Save> and <Close>

When you run WinTV v6, the list of TV channels will now include the name you just created. To see the list of TV channels and sources, either click channel up

or channel down until you see your video source listed, or click your left mouse button on the TV window and select Channel list.

Select this channel and you will have audio and video from your external source.

Changing the Channel List

Click on the Button MENU and “Suite-Manager” to open the channel manager. Select the <Channels> tab.

Channel Delete

To delete a channel you can either highlight and channel and the right click and select delete or highlight the name of the channel and press the “DELETE” key on your keyboard. In order to delete the full channel list you can <Select All> and then delete.

Channel Rename

To rename a channel you have to highlight it and then click on the column “Preferred Name”.
You can then edit the name of the channel.

Channel Number Location

Highlight the channel that you want to change in the column “Preferred Number”. You can now enter a new number that is not already assigned to another channel.
To move a channel up or down the list, highlight the channel and then click on the “Move Channel (UP/DOWN) entry.

Favorite channel list

You have the option of creating a favorites channel list in the order that you want. Simply click on the channel name on the right hand side and drag the channel name to the left on top of the Favorite group on the left hand side window.

Creating a new favorites group

You can also create a new channel suite if you prefer to create a new favorites group. Click on the Add Suite and type in a name for the new suite. If you then highlight “All Channels” you can then drag the channel on the right hand window into the new suite that you have created. This is useful if you only want some channels to be shown in your TV channels list.

Menu Options

Clicking on the “MENU” button will give you the following options:

“4 x 3”
Select the TV picture aspect ratio 4 x 3.

“16 x 9”
Select the TV picture aspect ratio 16 x 9.

“Select Channel”
Select the channel that you want to view.

“Suite Manager”
Opens the channel suite manager where you can scan for channels and configure video input.

'Configuration” Menu
Allows you to configure the “Channels...”, “Audio”, “Snapshots...”, “Preferences...” and “MPEG Settings”.

“View” Menu
Allows you to set the TV image screen size to a pre-defined size (320 x 240, ..., 800 x 600).

“Options” Menu
To select the option ensure that the tick is selected before the name of the option.

“Select suite”
Allows you to select a specific suite (TV, Radio or favorites), you can also select your own created suite.

Options - Always on Top
Always on top will always make WinTV be visible on your windows desktop, it will be on top of any application.

Options - Aspect Radio
This option will force the aspect ratio to 4 x 3.

Options - Mute
Will Mute and un-mute the sound.

Options - No-Title
This option will remove the TV applications borders, so you will only have the TV picture.

Options - TV Mode
This option will change the TV picture to Full Screen mode, so the TV picture will cover the whole of the desktop.

“Display” Menu

Display - Freeze
Will stop the TV picture from moving. You can also press: <CTRL> + <F>.

Display - Preferences...
Allows you to configure the “WinTV Preferences”.

“File” Menu

File - Save as
After using the “Snap” button you will be able to save that still image snapshots to different file formats (e.g. Jpeg, BMP etc).

File - Print...
Allows you to print out the still image snapshot.

File - Print setup
Allows you to configure the printer settings.

File - Copy
Allows you to copy the still image snapshots to the clipboard of Windows.

File - Exit
Will close down the TV application. You can also press <Alt> + <F4> on the keyboard.

“Help” Menu
Help - Help Topics
Opens the online help menu.

Help - Tip of the Day
Shows the tip of the day for useful information about the application.

Help - About
Shows information about the application version files and hardware.

WinTV Settings

Click the Configuration button on WinTV to see the WinTV Settings menus. There are three tabs: View, Movies and Snapshot.

View menu

On Screen Display
The “On Screen Display” allows you to set the amount of time the information bar will be displayed on the screen. The annunciator font allows you to change the font type and color that will be used.

Tab - Title mode (TV picture with application Menu)
4:3 Aspect Ratio
The option '4:3 aspect ratio' determines whether this is automatically selected, if you re-size the WinTV window with the mouse.

Enforce Aspect ratio
When checked, the image's aspect ratio is preserved as the WinTV window is scaled. Selecting Enforce Aspect ratio will round off the height and width dimensions of the television image in order to maintain the proper aspect ratio. WinTV can operate as a Screen Saver, or can retain your current Screen Saver. If Allow Screen Saver is checked, choosing the 'Use System Screen Saver' option uses any current screen saver configuration on your computer. Choosing TV Mode uses WinTV (in full-screen mode) as the system screen saver.

Tab - No Title mode (TV picture only)
No Title Mode Displays the Television inside the application window, without Title and Menu bars. This configuration dialog provides Aspect Ratio and Screen Saver settings as described in Title Mode (above).

Tab - TV Mode (Full screen TV)
TV Mode displays the television image using the entire height and width available to the monitor screen.

Movies menu

DVCR Record File Path
Refers to the folder of the recorded video files.

Pause Mode Record Path
Refers to the temporary path of the file that is buffered during the pause mode.

Pause Buffer
This sets the maximum size of the Pause Buffer.

Quality Level
Allows you to set the quality level of the recorded MPEG files files, example “DVD 6Mb” for analog recordings.
Note: For digital TV recordings of ATSC, clear QAM, DVB-T, etc. WinTV records using the actual digital format. You will see 'DVD 2048 bytes' which refers to the native video quality.

Snap Shot menu

Clicking on the CFG icon allows you to configure the Snapshot settings:

Capture resolution
Capture Resolution Images in WinTV are captured at the maximum resolution. When the image is saved to a file name (below), you select a resolution for the snapshot, from 320 x 240 (minimum) to 1600 x 1200 (actual size).

Fields Captured
Fields Captured Broadcast video uses an interlaced format, in which the odd-numbered scan lines and even-numbered scan lines are displayed separately; the eye combines them into a smooth image. On the computer monitor output, both fields are displayed at once. When taking a snapshot of a video image with little motion, Capture 2 Fields produces the most data and the clearest image. However, when taking a snapshot of a video image containing motion, capturing both fields may result in a blurred image. Therefore, use Capture 1 Field for best results. Experiment with these settings to achieve the desired results.

Default
Button Resets Snapshot Configuration to factory defaults.

Audio Settings

Note: This option is only available on a WinTV product that supports this feature and will only be displayed if you are tuned into a channel or video input that supports this feature.

Audio Mixer Inputs
Click on this item to display a list of possible selections: WinTV WAVE should be selected.

Current TV Audio preferences
This area enables you to select audio preferences, from the source dependent Available

Modes listing at the bottom of the dialog box.

Current TV Available Modes
The actual (active) setting is highlighted.

Color Settings (analog only)

Note: This option is only available on a WinTV product that supports this feature and will only be displayed if you are tuned into a channel or video input that supports this feature. Not available for ATSC or Clear QAM channels.

Here the brightness, the contrast, the saturation and hue can be changed for improving the picture quality for analog sources. Selecting default changes the settings back to default settings.

Pause, Record, and TV mode

There are four buttons to control the Watching, Recording and Pausing of TV.

Clicking on the Pause button will cause the Pause menu to roll down from the WinTV application, while clicking on the Record button will cause the Record menu to roll down.
Clicking on the Record will start a recording of the channel that you are watching. If you click on the button once, it will record for 15 Minutes, clicking twice will record for 30 minutes, clicking a third time will record for 45 minutes. Each click will record for another 15 minutes
(So 3 clicks will record for 45 minutes).

Background Recording

The background recorder (BG recorder) allows you to record your program without the WinTV application opened on your desktop. When the background record starts; a red bullet icon close to the Windows clock starts. You can end the recording by right clicking on this icon and selecting terminate recording.

Click diagram to enlarge.

Time counter
The time is specified in a Hour:Minute:Second format..

Record

Clicking the Record button will automatically generate a file name and start recording your audio/video program.

The Live TV window will be shown in the TV window
The time counter will indicate the length of recording
When recording using One Touch Record then length of the recording will be shown.

The quality of the recording and the hard disk space can be specified by clicking the symbol
Preferences//Movies/MPEG. If you click on 'stop', the timer counter is put back to 00:00:00.

Stop

Clicking the Stop button will stop the video you are recording or playing back.

Play

Clicking the Play button will playback from disk the last video file created. When playing a video, you can rewind, fast forward, replay 10 sec or skip forward 10 sec using the buttons on the control bar.

Pause

Clicking the Pause button while Playing will pause your audio/video.

Rewind

Clicking the Rewind button will play the video file in reverse. Clicking the Rewind button again will continue the playing of the video.

Fast-Forward

Clicking the Fast Forward button one time will fast Forward your video at 2X speed. Clicking the Fast Forward button two times will fast Forward your video at 8X speed. Clicking the button again will continue playing back at normal speed.

Slow Motion

Clicking the Slow Motion button during playback will cause the video to play in slow motion. Clicking the Slow Motion button again will return the video to normal playback speed.

File

Clicking the File button opens the File menu. The last file recorded is listed in the File name box. In the File menu you can:

Rename your recorded video file: To rename a video file, find the file you would like to rename, highlight it with your mouse, and click and hold the right mouse button. Go down to
Rename and then you can type in a new name. Remember: You must keep the MPG extension on the file.
Play a video file previously recorded: Find the file you would like to play, highlight it with your mouse (one click of the mouse button) and click Open. Then click the Play button.
Delete recorded video files which you no longer want: Click your right mouse button on the video file once, go down the menu and click Delete

Pause-Mode

The pause mode allows you to pause the TV or Video window. Clicking the Pause button on the WinTV application starts the Pause mode. The Pause Menu will drop down.

Click diagram to enlarge.

Pause-Buffer

The Pause buffer is space on your hard disk where video is stored during the Pause mode.
The maximum amount of time which your TV program can be delayed is dependent upon how much storage space you have set for the Pause buffer. To change the default pause buffer location licking the symbol spanner//Movies/MPEG.

Delay counter

The delay counter indicates the amount of time that the Live video window has been paused.
If the delay counter indicates 00:01:23 then the Live video window has been paused for 1 minute and 23 seconds.

Rewind

Clicking the Rewind button while playing video will rewind the recorded video. Clicking the Rewind button again will continue the playing.

Pause

Clicking the Pause button causes WinTV to start recording into WinTV's Replay Buffer. It takes about 10 seconds for the Replay Buffer to be initialized and for Pause to become effective. Un-clicking the Pause button will cause the audio/video program to start playing from the point where the button was originally clicked.
Most WinTV functions are active while in the Pause or Pause Live mode. For example, you can change volume, resize the TV window, go into 'no-title mode', etc. While in Pause mode, the Video Position bar shows the amount of the Replay Buffer which is filled with video. For example, if the Video Position indicator shows halfway, it means that half of the Replay Buffer is filled. If you find you cannot Pause as many minutes as you would like, increase the size of the Replay Buffer.
While in Pause mode, the A/V stream is always saved in the Replay Buffer. To stop saving the A/V stream in the Replay Buffer, you must exit the Pause mode by clicking TV mode.

Slow Motion

Clicking the Slow Motion button while playing video will play in Slow Motion. Clicking the Slow Motion button again, will continue playing normally.

Fast-Forward

Clicking the Fast Forward button one time will fast forward your video at 2X speed. Clicking the Fast Forward button two times will fast forward your video at 8X speed.

Replay

While in the Pause mode, hitting the Replay button acts like the Instant Replay you see on TV broadcast sporting events: the audio/video goes back in time and you repeat what you have previously seen. Each click of the Replay button causes audio/video to go back 10 seconds.
For example, if you want to repeat the audio/video you saw 10 seconds ago, you would click the Replay button once. If you want to see the video you saw one minute ago, you would need to click the Replay button six times.
For extended replay times, you might find it more convenient to grab the Video Position indicator control bar and move it to the left. Once you let the control bar go, audio/video starts to play (it might take a few seconds for the WinTV application to start playing).
You might have to move the Video Position indicator to the left and right to find the desired spot to start replaying audio/video. While Replaying, your audio/video program continues to be recorded in the Replay Buffer. Therefore, if you have clicked the Replay button 3 times (so that you are replaying the audio/video seen 30 seconds ago), the video you see in the WinTV window will be 30 seconds behind the 'live' audio/video program.

Skip Ahead

Clicking the Skip button will skip the video ahead 10 seconds.

MPEG compression formats

Note: Only available on supported products (PVR / HVR that use a 'hardware encoder')

The WinTV supports several formats for MPEG video compression, called Quality Levels. The differences in these formats are:

The higher the datarate, the better the video quality you see from live TV and your recordings. The higher the datarate, the more disk space which will be required.
CPU horsepower required during playback and pause mode.
The compatibility when creating Video CD’s or S-VCD’s.

To configure the MPEG Quality Level, on WinTV click the Preferences button, then Capture and then the MPEG tab. Here are the video formats and the amount of disk space per hour used:

MPEG2 2.0MBits/sec (Full D1) .9 Gigabytes/hour
MPEG2 2.0MBits/sec (Half D1) .9 Gigabytes/hour
MPEG2 12.0 MBits/sec (Full D1) 5.4 Gigabytes/hour
MPEG2 12.0 MBits/sec (CBR) 5.4 Gigabytes/hour
DVD Standard Play 8.0Mbits/sec 3.1 Gigabytes/hour
DVD Long Play 6.2Mbits/sec 2.4 Gigabytes/hour
DVD Extra Long Play 2.5 Mbits/sec 1.2 Gigabytes/hour
SVCD Standard Play 2.5Mbits/sec .8 Gigabytes/hour

Note: CBR is constant bit rate, VBR is variable bit rate.

Which record format should you use?

If you would like to burn a DVD, then chose either DVD Standard Play, DVD Long Play or DVD Extra Long Play. DVD formats record at 720x480 (720x576 with PAL video sources) using 48.0 kHz stereo audio.
If you want to watch the recorded video on your PC, for the best video quality chose MPEG2 12.0MB/sec or DVD Standard Play. If you do not have much disk apace, try the MPEG-2 2.0MB/sec.
SVCD is a nice compromise between video quality and hard disk space. Video is recorded at 480x480 (480x576 for PAL video) at a datarate up to 2.5Mbits/sec.
Once chosen, the Quality Level format is set for both the Pause and Record modes. The format cannot be changed while Recording or while in the Pause mode.
DVD players which are compatible with CD’s and MP3’s can also read DVD’s burned using MPEG video files created with the WinTV.

Creating a DVD

If you plan to burn a DVD using a authoring software package, you should use either the “DVD Standard Play”, the “DVD Long Play” or “DVD Extra Long Play”. These formats will allow you to make DVD’s with the following recording lengths:
DVD Standard Play: 1 hour 30 minutes on DVD+R/RW disks
DVD Long Play: 1hour 50 minutes on DVD+R/RW disks
DVD Extra Long Play: 4 hours on DVD+R/RW disks

Keyboard Shortcuts

The following keys can be used to access WinTV directly from your keyboard:

In Live TV Mode:

Channel Up	=	Plus (+)
Channel Down	=	Minus (-)
Volume Up	=	Page Up
Volume Down	=	Page Down
A Channel Number	=	0-9 Enter
Take a snapshot still image capture	=	Spacebar
Exit Full Screen Mode	=	Esc
Open Online Help	=	F1
Mute Sound On/Off	=	CTRL + M
Freeze TV Image	=	CTRL + F
Copy To Clipboard	=	CTRL + C
Snapshot Print	=	CTRL + P
Video Source Select	=	CTRL + S
Re-size the TV window to and from Full Screen	=	CTRL + T
Show EPG information	=	CTRL + I
Re-size the TV window to default size	=	Alt + M
Start the Pause-function Timeshift	=	Alt + P
Start the recording function	=	Alt + R
Opens the snapshot save options	=	Alt + F
Close the application	=	Alt + F4

During recording:

Channel Up	=	Plus (+)
Channel Down	=	Minus (-)/td>
Take a snapshot still image capture	=	Spacebar
Stop recording	=	Esc
Open online help	=	F1
Snapshot Print	=	CTRL + P
Freeze TV Image	=	CTRL + F
Copy To Clipboard	=	CTRL + C
Mute Sound On/Off	=	CTRL + M
Re-size the TV window to and from Full Screen	=	CTRL + T
Pause the Live TV window (has no effect on the recording)	=	Alt + Q
Increase record time by 15 min intervals	=	Alt + R
Start the Pause-function Timeshift	=	Alt + P
Opens the snapshot save options	=	Alt + F
Stop recording and return to Live TV mode	=	Alt + N
Close the application	=	Alt + F4

In TimeShift-Mode (Pause mode):

Channel Up	=	Plus (+)
Channel Down	=	Minus (-)
Take a snapshot still image capture	=	Spacebar
Snapshot print	=	CTRL + P
Copy to clipboard	=	CTRL + C
Mute sound on / off	=	CTRL + M
Re-size the TV window to and from Full Screen	=	CTRL + T
Pause the Live TV window	=	Alt + Q
Pause-Mode stops and recording start	=	Alt + R
Start the Pause-function Timeshift	=	Alt + P
Opens the snapshot save options	=	Alt + F
Exit pause mode and return to Live TV mode	=	Alt + N
Close the application	=	Alt + F4

WinTV v8 application and TV tuner driver download package

This is WinTV v8, which can be used if you have a WinTV v7 CD-ROM. If you have a WinTV v8 Activation Code, you can upgrade to WinTV v8.5 at no cost.

Installation notes for WinTV v8:

WinTV v8 is primarily for the Hauppauge WinTV-HVR-850, WinTV-HVR-950, Colossus (not Colossus 2), HD PVR model 1212, WinTV-HVR-1150, WinTV-HVR-1500 or WinTV-HVR-1600. WinTV v8.5 does not support these products.

Activation for this version of WinTV v8 is done with your WinTV v7 CD-ROM or WinTV v8.5 Activation Code.

WinTV v10 Activation Code: If you do not have a WinTV v8/8.5 Activation Code, you can purchase the new WinTV v10 Activation Code on the Hauppauge webstore for $12.95. This can be used with all products supported by WinTV v8 and WinTV v8.5

WinTV v8 installer
For Windows 10, 8, and 7

File name: wintv8setup_35167.exe | File size: 108 MB | Date: June 23, 2017
Release notes | Backup download site

This download is a complete installation package, including drivers for supported WinTV products plus the WinTV v8 application and utilities.

To install the WinTV v8 application

Download the WinTV v8 installer to your PC. After downloading this file, it's normally saved in the Download directory on your PC
Note: If you see a message Run or Save?, click Save.
Have your WinTV Activation Code ready or insert your original valid WinTV v7 CD
Run wintv8setup from the Download directory on your PC
At Activation required, click Check WinTV CD if you have a WinTV v7 CD or click Enter Serial Number and then enter your WinTV Activation code.

This will complete the driver and application installation for your WinTV.

To install WinTV v8 on a PC or laptop without a CD-ROM drive

If your PC or laptop does not have a CD-ROM drive, do the following:

At the conclusion of the installation a dialog box will pop up saying 'Activation required'
Click Enter Product Code
You will find the Product code on your WinTV v7 Installation CD
Enter the Product code including dashes and dots

To find your Product Code

Look at the following guide for finding your product code

Note: If you have a WinTV v7.2 CD-ROM with Extend, the latest version of WinTV v8 with Extend will also be installed.

New product installs:

If you have recently purchased a new WinTV product and your WinTV v8.5 Activation Code has never been used, you can install WinTV v10 with this code. This only applies to unused WinTV v8.5 Activation Codes.

Installation notes for WinTV v8.5:

If you have one of the following products: a Hauppauge WinTV-HVR-850, WinTV-HVR-950, the original Colossus or HD PVR model 1212, you must use WinTV v8 or WinTV v10. WinTV v8.5 does not support these products.

A WinTV v8.5 Activation Code will be needed to install this WinTV v8.5 version. If you do not have an Activation Code, but you have a WinTV v7 CD, you can install the WinTV v8 application.

If you do not have an Activation Code: If you do not have a WinTV v8/8.5 Activation Code, you can purchase the new WinTV v10 Activation Code on the Hauppauge webstore for $12.95. This can be used with WinTV-HVR, WinTV-dual and WinTV-quad products, as well as the HD PVR series of HD recorders plus USB-Live2 and the ImpactVCBe.

Extend: If you have an Activation Code for WinTV v8 or v8.5 with Extend, the latest version of WinTV v8.5 with Extend will automatically be installed.

Installation on multiple computers: the WinTV application can be installed on as many PCs as needed as long as you use the same Hauppauge device. We link the serial number of your TV tuner (sometimes it's the MAC address) with the Activation code. So as long as you use the same Hauppauge device, you can install on more than one computer.

WinTV v8.5 application and Windows driver package

This download is a complete WinTV v8.5 application, including Windows drivers for supported WinTV products plus utilities.

WinTV v8.5 Installer
For Windows 10, 8, and 7

Version: 37352 | File size: 103 MB | Date: Dec. 25, 2019
Release notes | Backup download site | Previous version

To install the WinTV v8.5 application

Step 1: Download the WinTV v8.5 installer by clicking the download button above. The WinTV v8.5 Installer is normally saved in the Download folder on your PC
Step 2: Run wintv85setup from the Download folder on your PC. Halfway through the installation, a message will pop up asking for you to enter the Activation Code.
Step 3: At the Activation required screen, click on Enter Activation code and enter the activation code which was emailed to you, is printed on the WinTV v8 activation card or printed on your WinTV v8 CD. You do not need to enter the dashes, and you can use upper or lower case characters.
Step 4: When the installation is complete, you will find the WinTV icon on your Windows desktop. Double click on this icon and the WinTV application will run. On the first run of WinTV, it will automatically go through the TV source selection and will scan for channels.

Keyboard Control in WinTV

Next Channel Plus (+)
Previous Channel Minus (-)
Increase Audio Volume 'Page Up'
Decrease Audio Volume 'Page Down'
Mute 'Ctrl + M'
Enter Preset Number '0 - 9'
Show Channel List 'Ctrl + L'
Make Snapshot 'Space Bar'
Show Now/Next 'Ctrl + O'
Display Stream Details 'Ctrl + D'
Subtitles on / off 'Ctrl + S'
Change Aspect Ratio 'Ctrl + A'
Pause Live TV 'Ctrl + Q'
Continue Live TV 'Alt + P'
Skip Ahead 'Ctrl + F'
Skip Back 'Ctrl + R'
Jump to Live Position 'Ctrl + C'
Full Screen 'Ctrl + W'
Exit Full Screen 'Esc'
Start TV 'Alt + T'
Start Recording 'Alt + R'
Stop Recording / Playback 'Alt + S'
Open File for Playback 'Alt + F'
Open WinTV Settings Dialog 'Ctrl + I'
Exit Application 'Alt + F4'

Where can I find the manual for WinTV?

In WinTV v8, right click your mouse in the live TV window, and go to Help. You will see our online manual.

You can also find the manual on our website in the Support -> WinTV v8 under the Manuals tab.

What do I need to upgrade the WinTV application from the Hauppauge website?

In order to upgrade to WinTV v8.5, you must have your WinTV v8 Activation Code. If you do not have an Activation Code , but you have a WinTV v7 CD, you can install the WinTV v8 application (look in the Support -> WinTV 8 Download tab).
If you do not have either a WinTV v8 Activation Code or your original WinTV v7 CD-ROM, you can purchase a new WinTV v8 Activation Code on the Hauppauge webstore for $9.95. The WinTV v8 Activation Code can then be used to activate WinTV v8.5

How do I rescan channels?

In WinTV v8, click on the setting button (Gear) in the lower left of the application. Then click on the Devices tab and highlight your WinTV device and click Tuner Setup (see the first picture below).

In the Device Setup Wizard, you will see a list of TV formats which your Hauppauge TV tuner can support. Depending upon which Hauppauge tuner you have, you will have a choice of analog, digital or external inputs (see the second picture below). You can also select all formats and let the WinTV application show you what it finds in each format (if anything).

Click Next and Next and let WinTV scan for channels. The results should look like picture 3 below.

Settings -> Devices

click to enlarge

Device Setup Wizard

click to enlarge

Scan Complete

Att Tv Channel Numbers

click to enlarge

I selected a channel but I just see 'buffering' in WinTV. Also there is no TV, just a blank screen

Buffering and no TV video can be caused by a few things:

If there is a problem with your TV signal. Check your antenna or coax cable going to the Hauppauge product.
If your anti virus software is preventing the WinTV application from making a temporary video buffer. If this is the case, you'll need to either disable the anti-virus software or create an exception for the WinTV application in your anti-virus exception list.
If you using a cable TV or satellite box, make sure the box is turned on.

I scanned for channels, and some were found, yet I do not see any channels listed in WinTV's channel list. What did I do wrong?

If you see channels during the scan, but no channels are listed in WinTV channel list (to see the channel list, right click your mouse on the live TV window, then select Find Channel), then something went wrong in the WinTV TV channel database.

Solution:

Uninstall WinTV completely: go to start/control panel/ and look for Program and feature and uninstall Hauppauge WinTV.
After that please restart the computer.
When the system comes back up please browse to the following folders and if you see a WinTV folder, delete the folder.
- C:UsersPublic
- C:Program Files or Program Files (x86)
- Also please go to this folder which is a hidden folder and delete the Hauppauge folder: C:ProgramData
  Information on how to show hidden folders in Windows: Show Hidden Files and Folders in Windows 7, 8.x, 10, or Vista http://www.howtogeek.com/howto/windows-vista/show-hidden-files-and-folders-in-windows-vista/
Once you do this you can reinstall Hauppauge WinTV with latest version from website.
Now if you scan for channels, you should see them in the WinTV application.

Our local TV channel switched frequencies today. I've been unable to get the rescan to work. I can find all the channels on the rescan but can't seem to save them in the database.

We recommend that you delete the WinTV channel database before you re-scan for channels, especially if you think that your channel line up has changed. To do this, close the WinTV v8/v8.5 application and then run this program:
c:Program Files (x86)WinTVWinTV8WinTV8.exe -emptydb

I'm trying to schedule a recording with TitanTV, but the scheduled recording does not show up in the WinTV Scheduler

The channel list in TitanTV must match the channel list in WinTV. If, for example, you scanned WinTV with an over-the-air antenna but selected a cable TV line up in TitanTV, your channel line will be different and scheduled recordings will fail.

To understand why this happens, lets look at how the process of clicking the record button in TitanTV and how this turns into a WinTV Scheduled recording. When you click the red 'record' button in TitanTV, Titan delivers a .tvpi file to your PC which contains the details of the recording (channel number, channel name, time, date, etc.). But if the channel number doesn't match a channel which WinTV can tune to, WinTV ignores this attempt to schedule the recording and you will not see this scheduled item in the WinTV Scheduler.

There is a log file saved at c:userspublichauppauge wintvlogswintvtvpi.txt which shows the details of an attempt to schedule a TitanTV recording. Click here to see a sample of this information.

Can I record while my PC is sleeping?

Yes.
Make sure your PC is in Sleep and not Hybernate. In Windows 'sleep' mode, WinTV recordings will cause your PC to 'wake up', start the recording and when complete, go back to Sleep.

How can I save my WinTV Channels database?

To avoid having to rescan for TV channels, you can save the list of channels you are using. This is called Saving the WinTV Channels database.

To save your channel database go to:

C:UsersPublicWinTVChannel Database (Windows 7 and Vista)

C:Documents and SettingsAll UsersShared DocumentsWinTVChannel Database (Windows XP)

Copy the hcwChanDB_5 file to a place for safe keeping. To replace saved Channels just copy HcwChanDB_5 back to Channel Database Dir.

How can I reorder or change the channel numbers in WinTV?

Open the Settings menu in WinTV v8 by clicking on the “gear” button in the lower left hand corner of the WinTV application. Then click on the “All Channels' tab and right click on the channel you wish to edit. Click Details. Change the Preset number to the number you want. You can also change the channel Name.

Example:
You will need to follow this procedure if you are scheduling recordings with Titan TV online program guide. For example, if you scan for TV channels in WinTV v7 and find that channel 2704 is WNBC but in the TitanTV electronic program guide WNBC is on channel 702, then do the following:

click your right mouse button on 2704 in the All Channel list
change the Preset to 702
change the Name of the the channel to WNBC
Then, when you select WNBC (channel 702) in TitanTV, it will tune to channel 2704, which is WNBC.

How can I add a single channel in the WinTV application?

Yes.
To add a single channel, go to Settings -> Devices and choose your TV tuner. Then click Tuner setup and select the format of the channel you want to add (Digital ATSC, Digital QAM or Analog TV). For both the Starting and Ending channel use the channel number you want to add. Example, if you want to add Analog channel 3, then select 3 for both the Starting and Ending channel. Then click Scan. Since you are only scanning one channel, it should find this channel quickly and add it to the channel list.

Where can I find my recorded files?

The default directory for recorded files is:

C:UsersPublicVideos

You can change the default directory in WinTV v8 by clicking on the “gear” button, then the Capture tab. Here you will see the Recordings Directory.

In Windows XP, files are recorded to:

C:Documents and SettingsAll UsersShared DocumentsMy Videos

Can I record TV shows with subtitles or closed caption?

Yes.
If the program you are watching has subtitles when you record you will also get the subtitles as part of the recording. When playing back recorded files in WinTV v8, you can use settings menu to turn the subtitles on or off. ( recorded sub titles can only be seen when using the WinTV v8 application for playback.)

Can I view and record my game play from external game sources with WinTV?

Yes, as long as you can connect the game system to either S-Video or composite video on your WinTV product. If so equipped, you can view and record the game action using the WinTV application software. For close to real time video, and to eliminate the normal delay, go to Settings/Advanced options and put a check mark in Game mode. Restart the WinTV application for the change to take effect.

WinTV v8 Installation Problems

Some virus software will prevent the WinTV application from completing the installation. If you find this, you will need to temporarily disable the virus sofware.

Here are a couple of virus applications and how to disable them:

AVG: 1) Right-click the AVG icon in the system tray next to the clock. 2) Click Temporarily disable AVG protection. 3) Choose how long you want the protection to be disabled and whether to disable the Firewall as well 4) then click OK.

I am getting a black screen in WinTV, or I'm seeing choppy video images. What can cause this?

There are two main reasons why you might see a black window:

TV Signal strength:. If the TV signal strength is on the edge of being too low, you might see either a black screen where the live TV picture should be, or your live TV picture might be choppy. Also, be sure that the incoming signal from your video source is working properly.

Graphic display adapter related: The video graphics acceleration mode can cause choppy live video or possibly cause a black screen where the live TV picture should be. To optimize the video graphics mode, in the WinTV v7 application go to Settings and look under Video Renderer. EVR is the default setting. Try VMR 7, VMR 9, or overlay for better results. You may also try placing a check mark in “Use hardware acceleration when possible”.

If there is still no improvement, enabling extended logging in WinTV and emailing the log files to tech support will help in troubleshooting the problem. (To obtain extended logs, first go to Settings/Advanced options. Enable extended logging, exit WinTV and reopen it for the change to take effect).

What video format will WinTV record in?

There are two types of recordings WinTV v8 will make: recordings from digital TV and recordings from analog TV.

Recordings from digital TV (ATSC, DVB or QAM) stay in the original digital TV format and in the original video quality. WinTV will save the recordings in a transport stream format (.TS extension). These files may be converted to MPEG2 using options in the WinTV Configuration menu.

When recording from analog TV (NTSC or PAL), recordings are made using MPEG2. You can choose the quality of your analog recordings in the Settings menu under Capture and then Default Analog Recording Quality.

What software can I use to edit & burn the recorded files from WinTV?

When recording digital TV, all recordings are made in whatever format your digital TV is being transmitted in. For example, ATSC is transmitted as MPEG-2 and therefore WinTV recordings will be MPEG-2. The files will be .TS files.

When recording from analog video or analog TV, WinTV will record MPEG-2 video using a .TS format. To edit your videos, you can use any software editor that can work with .TS files or MPEG-2 files

What file size will the recorded videos be?

Digital Broadcasts (ATSC or QAM)

The file size of a digital signal capture depends on the bitrate of the digital signal. The bitrate is set by the broadcaster and cannot be user configured. Bitrates for digital signals can range anywhere from about 1.2 Mbits/sec up to 19.3 Mbits/sec. Most of the time these bitrates are variable and not constant. Capture sizes for ATSC & QAM recordings range from approximately 1.7 Gigabytes per hour up to 8.3 Gigabytes per hour.

Analog TV or analog video

The WinTV application converts analog signals to digital in order to record. There are four recording profiles. The following list shows recording file sizes for burning to 4.3Gb DVD:

Best - Approx 1 Hour+
Better - Approx 1 1/2 Hours
Good - Approx 2 Hours
Fair - Approx 3 Hours

How do I scan for FM radio channels? And once I have scanned for FM radio, how do I find these radio stations in WinTV?

On those WinTV products with FM radio, you can scan for FM radio channels:

click the Setup button (gear button) on the lower left hand side of the WinTV app
click the Device tab
Choose your WinTV product, and then click Tuner setup
you should see a list of video and audio sourcs available on your Hauppauge TV tuner. Click Analog FM Radio and then Next
under Stations, select either Automatic Scan if you want the WinTV application to scan for FM radio stations, or Manual Entry if you want to enter your FM radio stations one at a time
then click Next to start the FM radio scan
the scan is complete when the message Scan complete is displayed
click Next and Next and you will be back to the main WinTV application
to select your FM radio channel, right click your mouse in the TV window and select Find Channel. You will see your FM radio channels at the end of your channel list.

My Tv Channel Number

How can I see the WinTV v8 channel list all the time?

You can display the TV and FM radio channel list all the time by Right Clicking on the live WinTV v8 window to bring up Find channel. You will see the Channel list (see picture below).

In the upper right hand corner of the Channel list is a small 'pin' icon. Click this icon to 'pin' your channel list to the WinTV v8 window.

Keyboard shortcuts

Ctrl A Aspect ratio
Ctrl D Display the video and audio format of the TV program
Ctrl F Freeze the video
Ctrl Z Open TV Scheduler
Ctrl O View program details (digital TV program, where provided in the broadcast)
Ctrl S Display subtitles
Ctrl W Full screen toggle
Alt F Open File menu for playback
Alt M Open the Task Menu
Alt P Previous channel
Ctrl Q Pause
Ctrl P Play
Alt R Record
Alt S Stop
Alt T Start TV
Ctrl C Catch up
Ctrl > Skip ahead
Ctrl < Skip back

Problems running the WinTV application on Windows Server
